Ifor Williams DP120

The DP120 range combines a substantial maximum volume and gross weight (3500kg) with the option of a removable container. When the container is removed, the DP120 can be used as a conventional flatbed trailer.

Body lengths of 10', 12' and 14' are availabe, all with standard headroom of 6'. A tri-axle is an option on the 12' model and standard on the 14' version. All sizes are available with either the standard ramp or with the EasyLoad™ ramp and folding deck system.

The trailer also includes aluminium ramp gates, pressure treated timber planking and slip-resistant aluminium treadplate flooring, receiver brackets for the optional cross division, side ventilation flaps and a split front access door

High Ramp Model
Fold-up aluminium treadplate sheep deck system with EasyLoad™ ramp and provision for stowage of deck supports and rear barrier inside the trailer

Low Ramp Model
Fixed-Panel ramp

Standard Equipment
Side vents and flaps
Split front access door
Rear ramp assistor
Aluminium ramp gates
Provision for carrying cross divisions and ramp gate extensions
Beam axle system with sealed-for-life unitized wheel bearings
Interior light
Security marking and registration with The Equipment Register (TER)
50mm locking ball coupling
Spare wheel and carrier

Optional Extras
Large and small cross divisions
Ramp gate extensions
GRP wind deflector
Removable dropsides, tailboard and headboard*
Loading skids (provision for stowage under platform)
Propstand kit

Ifor Williams trailers
Specifications Max. Gross Weight Internal Length Internal Width Headroom Tyres
DP120 10' 6' H/R 3500kg 3040mm (119 ½") 1880mm (74") 1890mm (74 ½") 185/60R12C
DP120 12' 6' H/R 3500kg 3660mm (144") 1880mm (74") 1890mm (74 ½") 185/60R12C
DP120 12' tri-axle 6' H/R 3500kg 3660mm (144") 1880mm (74") 1890mm (74 ½") 185/60R12C
DP120 14' tri-axle 6' H/R 3500kg 4280mm (168 ½") 1880mm (74") 1890mm (74 ½") 185/60R12C

Dimensions & weights are given as a guide only. Ifor Williams Trailers and Whitehall Trailers have a policy of continuous development. We reserve the right, therefore, to alter specifications without notice.
